WIKING Maxi 6 Wood Burning Stove — High-Efficiency Heating with Intelligent Control
The Wiking Maxi 6 wood burning stove delivers efficient and reliable heating performance for modern living spaces. Designed with WIKING® Autopilot™ technology, it combines intelligent combustion control with consistent heat output for clean and stable operation.
As a result, it offers strong performance, low emissions, and excellent fuel efficiency, making it a dependable choice for everyday home heating.
Performance and Efficiency
The Maxi 6 is engineered to provide balanced and efficient heating. Moreover, it delivers a nominal heat output of 6.6 kW with an 80% efficiency rating.
This ensures effective room heating while maintaining low fuel consumption. At the same time, the WIKING® Autopilot™ system automatically regulates airflow to maintain optimal combustion conditions.
Therefore, users benefit from a cleaner burn, improved efficiency, and reduced emissions during operation.
Technical Specifications
The stove is designed for flexible installation across different home setups. For example, it supports a 5”/6” smoke outlet, ensuring compatibility with a wide range of chimney systems.
In addition, it operates with a recommended chimney draught of 12 Pa when using WIKING® Autopilot™. Because of this, it maintains stable airflow and consistent combustion performance.
Certified Safety and Compliance
The Wiking Maxi 6 meets strict European standards for safety, performance, and environmental responsibility. In fact, it is fully certified under EN 16510 and EN 16510 Type CA requirements.
Furthermore, it is approved under BImSchV Stufe 2 and is DEFRA Exempt, making it suitable for use in regulated and low-emission zones. As a result, it meets some of the highest environmental standards in Europe.
Finally, the stove is Ecodesign compliant, ensuring modern efficiency and reduced environmental impact. Overall, the Maxi 6 delivers dependable heating, intelligent combustion control, and long-term reliability for contemporary homes.
To find out more about what a professional installation involves, visit our installation process page. For full technical documentation directly from the manufacturer, visit the official HWAM product pages for the WIKING Maxi 6 with wood store, WIKING Maxi 6 with lower door, WIKING Maxi 6 with wood store & natural stone cladding grey, WIKING Maxi 6 with wood store & natural stone cladding white, WIKING Maxi 6 with lower door & natural stone cladding grey, WIKING Maxi 6 with lower door & natural stone cladding white.
WIKING Maxi 6 Wood Burning Stove — Technical Specifications
Core Specifications — All Variants
The following specifications apply across the WIKING Maxi 6 range.
| Specification | Detail |
|---|---|
| Nominal Output | 6.6 kW |
| Efficiency | 80% |
| Energy Efficiency Class | A |
| Combustion System | WIKING® Autopilot™ |
| Smoke Outlet Diameter | 5″ / 6″ |
| Recommended Chimney Draught | 12.0 Pa |
| Combustion Chamber | 52.2 / 48.5 cm |
| External Air Intake | Rear or bottom (Ø 100 mm) – optional |
| Heat Storage Stones | 69.0 kg (where included) |
| DEFRA Exempt | Yes |
| Ecodesign Compliant | Yes |
| EN 16510 | Yes |
| EN 16510 Type CA | Yes |
| BImSchV Stufe 2 | Yes |
Dimensions & Weights — By Configuration
| Specification | Wood Store | Lower Door | Wood Store + Stone (Grey) | Wood Store + Stone (White) | Lower Door + Stone (Grey) | Lower Door + Stone (White) |
|---|---|---|---|---|---|---|
| Height | 119.3 cm | 119.3 cm | 122.3 cm | 122.3 cm | 122.3 cm | 122.3 cm |
| Width | 66.7 cm | 66.7 cm | 74.7 cm | 74.7 cm | 74.7 cm | 74.7 cm |
| Depth | 36.9 cm | 36.9 cm | 37.2 cm | 37.2 cm | 37.2 cm | 37.2 cm |
| Weight | 140 kg | 143 kg | 283 kg | 243 kg | 286 kg | 240 kg |
| Flue Connection Height | 82.6 cm from floor | 82.6 cm from floor | 82.6 cm from floor | 82.6 cm from floor | 82.6 cm from floor | 82.6 cm from floor |
| Minimum Floor Clearance | 0 cm | 0 cm | 0 cm | 0 cm | 0 cm | 0 cm |
Safety Distances — All Variants
| Distance to Combustibles | Detail |
|---|---|
| Behind (insulated flue) | 7.5 cm |
| Behind (uninsulated flue) | 15.0 cm |
| Side | 15.0 cm |
| Sides (in front of stove) | 45.0 cm |
| In front | 135.0 cm |
| Furnishing in front | 135.0 cm |
| Corner 45° | 7.5–10.0 cm (variant dependent) |
| Ceiling | 70.0 / 65.0 cm (variant dependent) |
| Mantel Piece | 70.0 cm |
