HWAM 4510m

Technical specifications
TECHNICAL DATA
Energy efficiency class HWAM? Autopilot?
A +
Energy efficiency class HWAM? SmartControl?
A +
HWAM? Autopilot?
Yes
HWAM? SmartControl?
Yes
Efficiency, HWAM? Autopilot? (%)
82.0
Efficiency, HWAM? SmartControl? (%)
81.0
Nominal heat output (kW)
4.9
Smokeoutlet (?)
6″
Chimney draught, recommended (Pa)
12.0
PRODUCT MEASUREMENTS (CM)
Height
75.5
Width
50.0
Depth
40.6
Combustionchamber
35.8
WEIGHT (KG)
Weight
99.0
CONNECTION MEASUREMENTS (CM)
From the lower edge of the stove without plinth, top
72.3
FRESH AIR KIT
Combustion air system can be mounted, back (? 100 mm)
Yes
Combustion air system can be mounted, back (? 100 mm)
Yes
DISTANCE TO COMBUSTIBLE MATERIALS, INSULATED FLUE GAS PIPE (CM)
Behind
10.0
Side
59.0
Sides, in front of the stove
59.0
In front
120.0
Furnishing in front
120.0
Corner, 45?
57.0
DISTANCE TO COMBUSTIBLE MATERIALS, UNINSULATED FLUE GAS PIPE (CM)
Behind
10.0
Side
59.0
Sies, in front of the stove
59.0
In front
120.0
Furnishing in front
120.0
Corner, 45?
57.0
APPROVALS
EN 13240
Yes
NS 3058/3059
Yes
LRV
Yes
BImSchV Stufe 2
Yes
RLU
Yes
DEFRA Exempt
Yes
UK CA
Yes
Classificazione
4 stelle
ECODESIGN Compliant. Yes
